INTIG 202 & 250 Pulse Digital Inverter Based MMA/TIG/PULSE Tig Welding machine General Information: Digital Inverter Based MMA / TIG / Pulse TIG Welding Machine INTIG PULSE Series machines are microprocessor controlled fully Digital lGBT Inverter based arc welding power source with advanced inverter technology. They are widely used for DC MMA, DC TIG & DC PULSE TIG welding In mild steel, alloy steel, stainless steel, copper & Titanium. Features: Advanced inverter technology, hence more reliability. Micro controller based technology for precise setting of welding parameters Under voltage, Over voltage, Phase absence and over heat protection. Digital preset of all welding parameters. High Efficiency, Better power factor. Built In High Frequency. 2/4 Step function. Built in gas control solenoid valve. Optional Accessories: Water circulation System, TIG Torch, Gas Regulator and remote controller. Basic Outfits: Power Source with wheels & Remote Socket for Torch Trigger Switch. Model : INTIG-202 Pulse : INTIG-250 Pulse Input Power (KVA): 7.5 : 9.8 Welding Current Range (A): 5-200 : 5-250 Peak/Base Current (A): 5-200 : 5-250 Start/Stop Current (A): 5-200 : 5-250 Weight (Kg): 19 : 23 Duty Cycle: 60% : 60% Dimensions (LxWxH mm): 530 x 240 x 400 : 530 x 270 x 420 Input Supply: 230V Single Phase 50Hz : 380-440 V 3-Phase 50 Hz Open Circuit Voltage (V): 75 : 75 Insulation Grade: H : H Up/Down Slope Time (Sec): 0-10 : 0-10 Pre Gas Time (Sec): 0-5 : 0-5 Post Gas Time (Sec): 0-60 : 0-60 Pulse Frequency (Hz): 0.2-99.9 : 0.2-99.9 Pulse Duty Cycle (%): 5-100 : 5-100 Efficiency at full load (%): 89 : 89 Power Factor: 0.95 : 0.95

INTIG 350 AC/DC OUTFIT AND INTIG 501 AC/DC OUTFIT General Information: DIGITAL INVERTER BASED AC/DC SQUARE WAVE TIG WELDING MACHINE INTIG-AC/DC Series machines are microprocesser controlled fully digital IGBT inverter based arc welding power source with soft switching technology. They are widely used for DC TIG, DC PULSE TIG / AC Square wave TIG and AC Square Wave Pulse TIG welding in various metals including Al. and Mg alloy. Features: Advanced Soft Switching technology, hence more reliability. Micro controller based technology for precise setting of welding parameters. Under voltage, Over Voltage, Phase absence and over heat protection. Digital preset of all welding parameters. Memory channels to store parameters. High efficiency, Better power factor. Light Weight but high duty cycle. Built in High Frequency.. Gas Check Facility. 2/ 4Step function. 14 ltrs.Water tank made from heat resistant PVC material. Specially designed Vortex Pump with brass body. Three Stage copper tube cooling radiator combined with separate. High Speed fan ensures efficient heat transfer to keep the torches cool. Water level indication. High Speed Cooling fan for Water Circulation Unit. Basic Outfits: Power Source with Wheels Water Cooling System Tig torches 4/8 mtrs. Regulator + Flowmeter Flowswitch Earthing Cable with clamp Trolley Starter Kit Remote socket for Torch Trigger Switch. Optional Accessories: Wired Remote Controller Model: INTIG-350 AC/DC OUTFIT : INTIG-501 AC/DC OUTFIT Peak / Base Current (A): DC 10-350 / AC 20-350 : DC 10-355 / AC 20-500 Input Power (KVA): 11 : 19.5 Open Circuit Voltage (V): 70-80 : 70-80 Max Welding Current (MMA/TIG): MMA 255 / TIG 350 : MMA 400 / TIG 500 Dimensions (L × W × H) mm: 1010 x 400 x 1340 : 1010 x 400 x 1380 Weight (Kg): 110 : 122 Input Supply: 380-440 V 3-Phase 50 Hz (Power Source), 230 V Single Phase 50 Hz (Water Circulation Unit) : 380-440 V 3-Phase 50 Hz (Power Source), 230 V Single Phase 50 Hz (Water Circulation Unit) Duty Cycle (%): 60% (40°C & 10 Min Standard) : 60% (40°C & 10 Min Standard) Efficiency (%): 85 : 85 Gas Pre Flow (Sec): 0-5 : 0-5 Post Gas Flow (Sec): 0-20 : 0-20 Up Slope Time (Sec): 0.1-10 : 0.1-10 Down Slope Time (Sec): 0.1-15 : 0.1-15 Pulse Frequency (Hz): 0.2-99.9 : 0.2-99.9 Pulse Duty Cycle (%): 10-90 : 10-90 AC Welding Frequency (Hz): 20-200 : 20-200 Power Factor: 0.9 : 0.9

INTIG 400 ID Inverter Based MMA/TIG Welding Machine General Information INTIG-ID Series machines are microprocessor controlled fully Digital lGBT Inverter based arc welding power source with soft switching technology. They are widely used for DC MMA, DC TIG welding In mild steel, alloy steel, stainless steel, copper & Titanium. Features: Advanced technology,hence more reliability Micro controller based technology for precise setting of welding parameters Under voltage, Over voltage, Phase absence and over heat protection. Digital preset of all welding parameters. High Efficiency, Better power factor. Light Weight but high duty cycle. Built in High Frequency. 2/4 Step function. Optional Accessories: Water circulation System, TIG Torch, Gas Requlator and remotecontrol. Basic Outfits: Power Source with Wheels & Remote Socket for Torch Trigger Switch Model: INTIG 400 ID Input Power (KVA): 18.4 Welding Current Range (A): 5–400 Start/Stop Current (A): 5–400 Duty Cycle: 100% Weight (KG): 43 Dimensions (LxWxH) mm: 600 x 320 x 590 Input Supply: 380~440V 3-Phase 50Hz Supply Open Circuit Voltage: 75 Volts Insulation Grade: H Efficiency at full load (%) : 89 Up/Down Slope Time (Sec.): 0 ~ 10 Power Factor: 0.9 Pre Gas Time (Sec.): 0 ~ 5 Post Gas Time (Sec.): 0 ~ 60
